Size: 10 HP
Features:
New 10 hp medium temp system to include:
(1) New 10 hp Krack mnfg outdoor condensing unit. Unit model HDSZ-1000MRMFF-D with Copeland scroll compressor. awef #7.60.
460 volt, 3 phase, r-449a.
Options included: air defrost timer and replaceable core suction filter.
Rating: 90,600 btuh @ +25 degree sst
(1) New Krack mnfg medium profile cooler evaporator. Model MSD46A-0949-RVB, air defrost, 14,720 cfm. 4-20” fans, 115 volt, 1 phase.
Options included: variable speed ec motors
Approx dim: 27” deep x 168” wide x 27” high. awef #9.00.
Rating: 94,900 btuh @ 10 degree td
Notes: system sized for +35 degree room temp, +25 degree sst, +95 degree ambient and operation on refrigerant r-449a. Controls for ec motors and evaporator txv not included.
- Voltage/Phase
- 3 Ph, 460 V
- Warranty
- 1 YR + 4 YR Extended
