Chandler HEL0065BY6EMAG0210 Electric Defrost Evaporator with IntelliGen

Chandler HEL0065BY6EMAG0210 Electric Defrost Evaporator with RDS and Controller

7,200 BTUH low-profile electric defrost evaporator built for walk-in freezers.

The Chandler HEL0065BY6EMAG0210 is a compact, 2 fan electric defrost evaporator designed for dependable cooling in commercial walk-in freezers. Its low-profile housing is ideal for installations where ceiling clearance is limited, while dual-speed EC motors deliver consistent, energy-efficient airflow.

·         New 7,200 BTUH low profile, electric defrost evaporator.

·         1 phase, 208/230 volt (2 fan unit).

·         Refrigerant: rated for operation on multiple A2L and A1 refrigerants.

·         Rating for other refrigerants and temperatures available upon request.

·         Options included: 2 speed EC motors, RDS ( required for A2L), and Intelligen Controller.

·         Approx. dim: 16” deep x 46” wide x 18” high, net wgt: 54 lbs.

·         Rating: 7,200 BTUH @ -20° SST/R-449a (AWEF #4.03).

·         Rating: 8,300 BTUH @ +25° SST/R-449a (AWEF #9.00).

·         Rating: 6,800 BTUH @ -20° SST/R-455a (AWEF #4.02).

·         Rating: 7,800 BTUH @ +25° SST/R-455a (AWEF #9.00).



RDS: Refrigerant Detection System includes mounted leak detection sensor, leak mitigation controller, early warning leak detection relay output for external alert devices and mitigation alarm with relay output for external alarm devices.

Intelligen Controller: controller includes electronic expansion valve, pressure transducer temp sensor, control board and user interface.
